HSRP Configuration: Explained

hsrp configuration

HSRP is a protocol that helps to achieve the failover. With the help of HSRP, we can configure active and standby routers and that goal is achieved with the help of a virtual IP. When active goes down, the standby router comes to the rescue. Let us understand the Cisco HSRP Configuration.

Given below is the topology that will help us understand the HSRP configuration.

hsrp configuration cisco

R1 is configured with 192.168.1.1 and R2 is configured with 192.168.1.2

192.168.1.254 is the virtual IP.



R1(config)#interface GigabitEthernet0/0/0

R1(config-if)#ip address 192.168.1.1 255.255.255.0

R1(config-if)#no shutdown

R1(config-if)#standby 1 ip 192.168.1.254

R1(config-if)#exit



%HSRP-6-STATECHANGE: GigabitEthernet0/0/0 Grp 1 state Standby -> Standby

This message will pop up.
R1 is now a standby router.
Why so?

Since we have not configured any priority, and the default priority is 100. So the router with a lesser IP Address becomes the standby while the router with a Higher IP address becomes an Active router.

Let's configure R2.

R2(config)#interface GigabitEthernet0/0/1

R2(config-if)#ip address 192.168.1.2 255.255.255.0

R2(config-if)#no shutdown

R2(config-if)#standby 1 ip 192.168.1.254

R2(config-if)#exit





%HSRP-6-STATECHANGE: GigabitEthernet0/0/1 Grp 1 state Standby -> Active

R2 becomes an active router since priority is 100 which is default but it has a Higher IP Address.

Verification

R1#show standby



GigabitEthernet0/0/0 – Group 1

State is Standby

8 state changes, last state change 00:18:38

Virtual IP address is 192.168.1.254

Active virtual MAC address is 0000.0C07.AC01

Local virtual MAC address is 0000.0C07.AC01 (v1 default)

Hello time 3 sec, hold time 10 sec

Next hello sent in 1.285 secs

Preemption disabled

Active router is 192.168.1.2

Standby router is local

Priority 100 (default 100)

Group name is hsrp-Gig0/0/0-1 (default)

R2#show standby



GigabitEthernet0/0/1 – Group 1

State is Active

5 state changes, last state change 00:05:14

Virtual IP address is 192.168.1.254

Active virtual MAC address is 0000.0C07.AC01

Local virtual MAC address is 0000.0C07.AC01 (v1 default)

Hello time 3 sec, hold time 10 sec

Next hello sent in 0 secs

Preemption disabled

Active router is local

Standby router is 192.168.1.1

Priority 100 (default 100)

Group name is hsrp-Gig0/0/1-1 (default)

Let us configure the priority value and make R1 an Active Router.

R1(config)#interface GigabitEthernet0/0/0

R1(config-if)#ip address 192.168.1.1 255.255.255.0

R1(config-if)#no shutdown

R1(config-if)# standby 1 ip 192.168.1.254

R1(config-if)# standby 1 priority 110

R1(config-if)# standby 1 preempt

%HSRP-6-STATECHANGE: GigabitEthernet0/0/0 Grp 1 state Speak -> Standby



%HSRP-6-STATECHANGE: GigabitEthernet0/0/0 Grp 1 state Standby -> Active

R1 goes from standby to Active since priority is set to 110 which is higher than default priority configured on R2 i.e. 100

R2(config)#interface GigabitEthernet0/0/1

R2(config-if)#ip address 192.168.1.2 255.255.255.0

R2(config-if)#no shutdown

R2(config-if)#standby 1 ip 192.168.1.254

R2(config-if)# standby 1 priority 100

%HSRP-6-STATECHANGE: GigabitEthernet0/0/1 Grp 1 state Speak -> Standby

The “preempthere in HSRP is used to specify that a router with a higher priority should automatically take back the role of the active (primary) router when it becomes available again after a failure.

Verification

R1#show standby

GigabitEthernet0/0/0 – Group 1

State is Active

5 state changes, last state change 00:02:11

Virtual IP address is 192.168.1.254

Active virtual MAC address is 0000.0C07.AC01

Local virtual MAC address is 0000.0C07.AC01 (v1 default)

Hello time 3 sec, hold time 10 sec

Next hello sent in 1.966 secs

Preemption enabled

Active router is local

Standby router is 192.168.1.2

Priority 110 (configured 110)

Group name is hsrp-Gig0/0/0-1 (default)

R2#show standby

GigabitEthernet0/0/1 – Group 1

State is Standby

3 state changes, last state change 00:02:29

Virtual IP address is 192.168.1.254

Active virtual MAC address is 0000.0C07.AC01

Local virtual MAC address is 0000.0C07.AC01 (v1 default)

Hello time 3 sec, hold time 10 sec

Next hello sent in 0.992 secs

Preemption disabled

Active router is 192.168.1.1

Standby router is localbl

Priority 100 (default 100)

Group name is hsrp-Gig0/0/1-1 (default)
